SPECIFICATION :

FRAME
FACT 8m carbon, 29" geometry, FACT IS construction, tapered headtube, carbon PF30 BB, 135mm dropouts, replaceable alloy rear derailleur hanger
SWAT
Bottle cage w/ SWAT Technology compatible (not included)
REAR SHOCK
-
FORK
RockShox Reba RL 29, Solo Air spring, alloy tapered steerer, lockout and reb adj., 15mm thru-axle, 15.5": 80mm Others: 90mm travel
HEADSET
1-1/8 and 1-1/2" threadless, Campy style upper with 1-1/2" lower, cartridge bearings
STEM
Specialized XC, 3D forged alloy, 4-bolt, 6-degree rise, 31.8mm clamp
HANDLEBARS
Specialized XC, flat bar, 2014 butted alloy, 700mm wide, 8-degree backsweep, 31.8mm
GRIPS
Specialized Sip Grip, light lock-on, half-waffle aramid-infused, 15.5"/17.5": regular, 19"/21": XL thickness
FRONT BRAKE
Formula C1, alloy caliper, metallic pad, 15.5"/17.5": 160mm, 19"/21": 180mm rotor
REAR BRAKE
Formula C1, alloy caliper, metallic pad, 160mm rotor
BRAKE LEVERS
Formula C1, hydraulic disc, tooled reach adj.
FRONT DERAILLEUR
SRAM X7, 10-speed, 34.9mm clamp, top pull
REAR DERAILLEUR
Shimano XT Shadow Plus, 10-speed, SGS long cage
SHIFT LEVERS
Shimano SLX, 10-speed, trigger
CASSETTE
SRAM PG-1030, 10-speed, 11-36
CHAIN
SRAM PC 1031, 10-speed, PowerLink
CRANKSET
Custom SRAM S-1250, 7050 alloy arms, 10-speed XC double, PF30 spindle, S: 170mm, Others: 175mm
CHAINRINGS
38/24
BOTTOM BRACKET
SRAM PF30, OS press-in bearings, sealed cartridge
PEDALS
-
RIMS
Roval 29, alloy disc, 26mm wide, 32h
FRONT HUB
Specialized Hi Lo disc, sealed cartridge bearings, 15mm thru-axle, 32h
REAR HUB
Specialized Hi Lo disc, double-sealed cartridge bearings, QR, 32h
SPOKES
DT Industry Stainless, 3X front/rear 2.0
FRONT TIRE
S-Works Fast Trak, 2Bliss Ready, 29x2.0", foldable aramid bead, 120 TPI
REAR TIRE
Specialized Fast Trak Control, 2Bliss Ready, 29x2.0", foldable aramid bead, 60 TPI
INNER TUBES
-
SADDLE
Body Geometry Phenom Comp, hollow Cr-Mo rails, 143mm
SEATPOST
Specialized 2014 butted alloy, single bolt setback, 27.2mm, 15.5/17.5" 350mm, Others: 400mm
SEAT BINDER
Specialized 7050 hard anodized alloy, single bolt, 32.6mm
