SPECIFICATION :

FRAME
M4 hydroformed tubing, 1.5" forged headtube, ISCG mounts, 135mm rear spacing, full-cartridge bearing pivots, 200mm travel
SWAT
-
REAR SHOCK
Custom X-Fusion Vector R, coil over w/ piggy back, adj. rebound, 8.5x2.5", spring rate XS: 350, S: 400, M: 450, L: 500
FORK
X-Fusion Vengeance R, coil spring, tapered alloy steerer, reb adj., 20mm thru-axle, 170mm travel
HEADSET
Semi-integrated alloy cups for 1-1/2" headtube and 1-1/8" steerer, cartridge bearings
STEM
Specialized P.Series MTB, forged alloy, 4-bolt, 40mm length, 31.8mm clamp
HANDLEBARS
Specialized DH, low-rise, 6061 alloy, 780mm wide, 9-degree backsweep, 6-degree upsweep, 31.8mm
GRIPS
Specialized Sip Grip, light lock-on, half-waffle aramid-infused, S/M: regular, Others: XL thickness
FRONT BRAKE
Avid Elixir 1, metallic pad, 200mm rotor
REAR BRAKE
Avid Elixir 1, metallic pad, 180mm rotor
BRAKE LEVERS
Avid Elixir 1 R, hydraulic disc, tool-less reach adj.
FRONT DERAILLEUR
-
REAR DERAILLEUR
SRAM X7, 9-speed, short cage
SHIFT LEVERS
SRAM X4, 8-speed, trigger
CASSETTE
SRAM PG-830, 8-speed, 11-32
CHAIN
KMC X-8, 8-speed, reusable Missing Link
CRANKSET
Truvativ Ruktion, 165mm, w/ Status guide
CHAINRINGS
34T steel, 4-bolt, compact 104mm pattern
BOTTOM BRACKET
Truvativ Howitzer XR, oversize sealed outboard cartridge bearings, 73mm shell
PEDALS
Alloy platform, 9/16"
RIMS
P.Disc, 32mm wide, 36h
FRONT HUB
Specialized Hi Lo disc, sealed cartridge bearings, 20mm thru-axle, 32h
REAR HUB
Specialized disc, bolt-on 135mm, 36h
SPOKES
Stainless, 14g
FRONT TIRE
Specialized Butcher SX, 2Bliss Ready, 26x2.3", foldable aramid bead, dual compound, 60TPI
REAR TIRE
Specialized Butcher SX, 2Bliss Ready, 26x2.3", aramid bead, dual compound, 60 TPI
INNER TUBES
Standard Schrader valve
SADDLE
Specialized DH, 8mm steel rails
SEATPOST
Specialized 6061 alloy, 2-bolt micro-adjust, no offset, 30.9mm, 300mm
SEAT BINDER
Specialized 7050 hard anodized alloy, w/ QR, 34.9mm, black
