SPECIFICATION :
FRAME
FACT 11m carbon, 29" geometry, FACT IS construction, tapered headtube, carbon PF30 BB, full internal shift/brake routing, 142+ dropouts, PM 160 rear brake, replaceable alloy rear derailleur hanger
SWAT
Bottle cage, EMT Tool, and Top Cap Chain Tool w/ SWAT Technology
REAR SHOCK
-
FORK
Custom RockShox SID World Cup 29 Brain, inertia valve damper, Solo Air spring, tapered carbon crown/steerer, top-mount Brain Fade and rebound adj., 15mm thru-axle, S: 80mm, Others: 90mm travel
HEADSET
1-1/8 and 1-1/2" threadless, Campy style upper with 1-1/2" lower, cartridge bearings
STEM
Syntace F109, 6-degree rise, 31.8mm clamp
HANDLEBARS
S-Works XC, flat bar, carbon, 700mm wide, 8-degree backsweep, 31.8mm
GRIPS
Specialized Sip Grip, light lock-on, half-waffle aramid-infused, S/M: regular, Others: XL thickness
FRONT BRAKE
Shimano XTR hydraulic disc, post mount, Ti/metal pad, Ice Tech, 160mm rotor
REAR BRAKE
Shimano XTR hydraulic disc, post mount, Ti/metal pad, Ice Tech, 160mm rotor
BRAKE LEVERS
Shimano XTR 985 hydraulic, w/I-Spec clamps
FRONT DERAILLEUR
Shimano XTR M986, down-swing, 34.9mm clamp, dual-pull
REAR DERAILLEUR
Shimano Shadow Plus XTR, 10-speed, GS mid cage
SHIFT LEVERS
Shimano XTR, 10-speed
CASSETTE
Shimano XTR M980, 10-speed, 11-36
CHAIN
Shimano XTR 981
CRANKSET
S-Works OS carbon, integrated 1-piece spider, 10-speed XC double, SRAM rings, S: 170mm, Others: 175mm
CHAINRINGS
38/24
BOTTOM BRACKET
PF30, OS press-in bearings, sealed cartridge
PEDALS
-
RIMS
Roval Control SL 29, carbon disc, 22mm internal width, 24h/28h
FRONT HUB
Roval Control SL 29, alloy hub body w/ Labyrinth seal design, 15mm thru-axle, 24h
REAR HUB
Roval Control SL 29 142+, DT Swiss Star Ratchet, 12mm thru-axle, 28h
SPOKES
DT Swiss Revolution, 2.0/1.5/2.0mm stainless
FRONT TIRE
S-Works Fast Trak, 2Bliss Ready, 29x2.0", foldable aramid bead, 120 TPI
REAR TIRE
S-Works Fast Trak, 2Bliss Ready, 29x2.0", foldable aramid bead, 120 TPI
INNER TUBES
-
SADDLE
Body Geometry Phenom Expert, hollow TI rails, 143mm
SEATPOST
Specialized carbon, 2-bolt, 27.2mm, S: 350mm, Others: 400mm
SEAT BINDER
Specialized 7050 hard anodized alloy, single bolt, 31.8mm
