SPECIFICATION :
FRAME
FACT IS-X 11m carbon front triangle, M5 rear triangle, tapered headtube, PF30 BB, ISCG '05 mounts, internal Command Post IR routing, 142+ dropouts, full cartridge bearing pivots, replaceable derailleur hanger, 165mm travel
SWAT
Bottle cage w/ SWAT Technology compatible (not included)
REAR SHOCK
Custom Cane Creek Double Barrel Air, high/low speed comp and reb adj., climb switch, 216x64mm
FORK
RockShox Pike RCT3, Solo Air spring, tapered alloy steerer, comp, lockout, reb, and threshold adj., 15mm thru-axle, 160mm travel
HEADSET
1-1/8 and 1-1/2" threadless, Campy style upper with 1-1/2" lower, cartridge bearings
STEM
Syntace F109, 6-degree rise, 31.8mm clamp
HANDLEBARS
Specialized All-Mountain, low-rise 7050 alloy, 750mm wide, 8-degree backsweep, 6-degree upsweep, 31.8mm
GRIPS
Specialized Sip Grip, light lock-on, half-waffle aramid-infused, S/M: regular, Others: XL thickness
FRONT BRAKE
Custom Avid X0 Trail, 4-piston caliper, steel backed metallic pad, 200mm rotor
REAR BRAKE
Custom Avid X0 Trail, 4-piston caliper, steel backed metallic pad, 180mm rotor
BRAKE LEVERS
Custom Avid X0, hydraulic disc, carbon blade w/ bearing, tool-less reach adj. w/ MatchMaker clamp
FRONT DERAILLEUR
-
REAR DERAILLEUR
SRAM XX1 Type 2, 11-speed, mid cage
SHIFT LEVERS
SRAM XX1, 11-speed, carbon/aluminum trigger, w/ MatchMaker clamp
CASSETTE
SRAM XX1, 11-speed, 10-42
CHAIN
SRAM XX1, 11-speed, hollow plates/pins, PowerLink
CRANKSET
SRAM XX1, carbon arms, single 34T ring, PF30 spindle, S: 170mm, Others: 175mm
CHAINRINGS
34T, 32T ring included
BOTTOM BRACKET
SRAM PF30, OS press-in bearings, sealed cartridge
PEDALS
-
RIMS
Roval Traverse SL, carbon disc, 22mm internal width, 27h/32h
FRONT HUB
Roval Traverse SL, 15mm thru-axle end caps, 27h
REAR HUB
Roval Traverse SL 142+, DT Swiss Star Ratchet, XX1 driver body, 12mm thru-axle, 32h
SPOKES
DT Swiss Super Comp, 2.0/1.65/1.8 stainless
FRONT TIRE
Specialized Butcher Control, 2Bliss Ready, 26x2.3", foldable aramid bead, 60TPI
REAR TIRE
Specialized Purgatory Control, 2Bliss Ready, 26x2.3", foldable aramid bead, 60 TPI
INNER TUBES
-
SADDLE
Body Geometry Henge Expert, Ti rails, 143mm
SEATPOST
Specialized Command Post IR, 3-position, internally routed adjustable height w/ air spring, remote operated, single bolt head, 30.9mm, S:100mm, Others: 125mm travel
SEAT BINDER
7050 hard anodized alloy collar, single bolt, 34.9mm
